Baumer VCXG - Field of View Position Accuracy; VCXG Field of View Accuracy; VCXU Field of View Accuracy

22
8.2 Field of View Position
The typical accuracy by assumption of the root mean square value is displayed in the
gures and the tables below:
± YM
± YR
± XR
Z
photosensitive
surface of the
sensor
front filter glass
for color cameras
thickness:
1 ± 0.1 mm
cover glass
of sensor
thickness: D
A
14,5±0,35
± XM
±
8.2.1 VCXG
Camera
Type
± x
M
[mm]
± y
M
[mm]
± x
R
[mm]
± Y
R
[mm]
± z
typ
[mm]
± α
typ
[°]
A
[mm]
D**
[mm]
VCXG-
53*
0.04 0,04 0.04 0.04 17.65 ± 0.070 0.6 16.5 0.55
8.2.2 VCXU
Camera
Type
± x
M
[mm]
± y
M
[mm]
± x
R
[mm]
± Y
R
[mm]
± z
typ
[mm]
± α
typ
[°]
A
[mm]
D**
[mm]
VCXU-
23*
0.04 0,04 0.04 0.04 17.63 ±
0.065 0.4 15.8 0.50
VCXU-
50*
0.11 0.11 0.11 0.11 17.63 ±
0.065 0.6 16.4 0.70
typical accuracy by assumption of the root mean square value
* C or M
** Dimension D in this table is from manufacturer datasheet
Figure7►
Sensor accuracy of the
Baumer CX series
