9. Camera Functionalities
9.1 Image Acquisition
9.1.1 Image Format
A digital camera usually delivers image data in at least one format - the native resolution
of the sensor. Baumer cameras are able to provide several image formats (depending on
the type of camera).
Compared with standard cameras, the image format on Baumer cameras not only in-
cludes resolution, but a set of predened parameter.
These parameters are:
▪ Resolution (horizontal and vertical dimensions in pixels)
▪ Binning Mode
9.1.1.1 VCXG
Camera Type Full frame Binning 2x2 Binning 2x1 Binning 1x2
Monochrome
VCXG-53M ■ ■ ■ ■
Color
VCXG-53C ■ ■ ■ ■
9.1.1.2 VCXU
Camera Type Full frame Binning 2x2 Binning 2x1 Binning 1x2
Monochrome
VCXU-23M ■ ■ ■ ■
VCXU-50M ■ ■ ■ ■
Color
VCXU-23C ■ ■ ■ ■
VCXU-50C ■ ■ ■ ■
