8.3.2 Single Frame Mode
In this mode the camera is captured one frame after AcquisitionStart. Then the acquisition
is stopped.
8.3.3 Multi Frame Mode
In this mode a predened number of frames will be captured after AcquisitionStart. The
AcquisitionFrameCount controls the number of captured frames. Then the acquisition is
automatically stopped.
8.3.4 Acquisition Frame Rate Mode
With this feature Baumer introduces a clever technique to the CX camera series, that
enables the user to predene a desired frame rate in continuous mode.
For the employment of this mode the cameras uses an internal clock generator that cre-
ates trigger pulses.
Notice
From a certain frame rate, skipping internal triggers is unavoidable. In general, this de-
pends on the combination of adjusted frame rate, exposure and readout times.
