9.7 Device Reset
The feature Device Reset corresponds to the turn off and turn on of the camera. This is
necessary after a parameterization (e.g. the network data) of the camera.
The interrupt of the power supply ist therefore no longer necessary.
9.8 User Sets
Four user sets (0-3) are available for the Baumer cameras of the VCX series. User set 0
is the default set and contains the factory settings. User sets 1 to 3 are user-specic and
can contain any user denable parameters.
These user sets are stored within the camera and can be loaded, saved and transferred
to other cameras of the VCX series.
By employing a so-called "user set default selector", one of the four possible user sets
can be selected as default, which means, the camera starts up with these adjusted pa-
rameters.
9.8.1 VCXG
Parameter
AcquisitionMode LineDebouncerHighTimeAbs
AcquisitionFrameCount LineDebouncerLowTimeAbs
AcquisitionStart Width
AcquisitionStop Height
AcquisitionFrameRate OffsetX
TriggerMode OffsetY
TriggerSource BinningHorizontal
TriggerActivation BinningVertical
TriggerDelay ReverseX
BalanceWhiteAuto ReverseY
ExposureTime PixelFormat
AcquisitionFrameRateEnable TestPatternGeneratorSelector
ReadoutMode TestPattern
Gain LUTEnable
Gamma LUTValue
BlackLevel DefectPixelCorrection
BrightnessCorrection ActionDeviceKey
ChunkModeActive ActionGroupMask
ChunkEnable ActionGroupKey
TimerDuration GEV SCPD
TimerDelay GEV SCFTD
TimerTriggerSource FixedPatternNoiseCorrection
TimerTriggerActivation DeviceLinkThroughputLimit
FrameCounter EventNotication
LineInverter
LineSource
UserOutputValue
UserOutputValueAll
