20. TECHNICAL SPECIFICATIONS
Model: ECO5 BLUE 24
Category - II2H3P
Gas used - G20 - G31
Rated heat input for DHW circuit. kW 26.3
Rated heat input for heating circuit. kW 26.3
Reduced heat input kW 10.6
Rated heat output for DHW circuit kW 24
Rated heat output for heating circuit kW 24
Heat output adjusted in heating kW 24
Reduced heat output kW 9.3
DHW / heating circuit max. water pressure bar 8 / 3
Expansion vessel capacity l 6
Expansion vessel minimum pressure bar 0.5
DHW min. dynamic water pressure bar 0.15
Minimum DHW ow I/min 2.0
Production of DHW with ΔT =25 °C I/min 13.7
Production of DHW with Δ T =35 °C I/min 9.8
Specic ow “D” (EN 13203-1) I/min 11.2
Temperature range in heating system °C 30/85
Temperature range in DHW circuit °C 35/60
Fumes typology - B
11BS
Diameter of ue duct mm 120
Max . ue mass ow rate kg/s 0.020
Min. ue mass ow rate kg/s 0.018
Maximum temperature of fumes °C 110
Minimum temperature of fumes °C 85
NOx Class - 6
Natural gas supply pressure 2H mbar 20
Propane gas supply pressure 3P mbar 37
Power supply voltage V 230
Power supply frequency Hz 50
Rated power supply W 60
Net weight kg 27
Dimensions (height/width/depth) mm 730/400/298
Humidity protection level (EN 60529) - IPX5D
CE Certicate N° 0085BM0324
CONSUMPTION AT HEAT INPUT Qmax and Qmin
Qmax (G20) – 2H m
3
/h 2.78
Qmin (G20) – 2H m
3
/h 1.12
Qmax (G31) – 3P kg/h 2.04
Qmin (G31) – 3P kg/h 0.82
