Fig.10

7.2Clearances(Figs.9&10)

1.Aflatverticalareaisrequiredfortheinstallationoftheboiler.

2.Thesedimensionsincludethenecessaryclearancesaroundtheboilerforcaseremoval,spanneraccessandairmovement.Additionalclearancesmayberequiredforthe

passageofpipesaroundlocalobstructionssuchasjoistsrunningparalleltothefrontfaceoftheboiler.

3.Ensurethatthereisadequateclearancefortheliftingequipment(GenieGL8liftingequipmentdimensionsare64cmwidex175cmhighx95cmdeep).

7.3VentilationofCompartments

1.Wheretheapplianceisinstalledinacupboardorcompartment,noairventsarerequired.

2.BS5440:Part2referstoroomsealedappliancesinstalledincompartments.Theappliancewillrunsufficientlycoolwithoutventilation.

page16

7.4GasSupply

1.Thegasinstallationshouldbeinaccordancewiththerelevantstandards.InGBthisisBS6891(NaturalGas)orBS54821(PropaneGas).InIEthisisthecurrentedition

ofI.S.813"DomesticGasInstallations".

2.Agasservicecockissuppliedtoenableconnectionusing15mmcopperpipe(Fig.11).

3.Ensurethatthepipeworkfromthemetertotheapplianceisofadequatesize,andthedemandsofanyothergasappliancesinthepropertyaretakenintoconsideration.It

isrecommendedthat22mmdiameterpipeisusedtowithin1moftheappliance.

Fig.11

7.5ElectricalSupply

1.Externalwiringmustbecorrectlyearthed,polarisedandinaccordancewithrelevantregulations/rules.InGBthisisthecurrentI.E.E.WiringRegulations.InIEreference

shouldbemadetothecurrenteditionofETCIrules.

2.Themainssupplyis230V~50Hzfusedat13A.
