Baxi ECOGEN 24/1.0 Installation & Servicing Instructions

Fig.21L
Fig.21m
page31
15.Foraestheticpurposesitispermissibletoroutethe60Øexhaustinanenclosedbox,buttheairinletandplumeoutletMUSTremaininfreeair.
16.Itisalsopossibletoseparatetheplumeoutletfromthe93°elbowtoallowthefluetobeinstalledasshowninFig.21n.
17.Todothis,firstslackenthetwoscrewsretainingtheplumeoutlettotheelbow,andremovetheoutlet(Fig.21p).Theelbowcannowbeusedtoconnecttheverticalto
horizontal60Øexhaust(Fig.21n).Retightenthescrewsintheelbow.
18.Theoutletcannowbefittedintothefemaleendofan60Øextensionpiece.Itmustbesecuredusingtwoofthescrewssuppliedinthebagwiththe'Jubilee'clip.
19.Markthefemaleendoftheextensionat30mmasshownintwopositions,directlyoppositeeachother(Fig.21q).
20.Usingasuitablebit(e.g.2mm),drillthroughtheextensionandoutlet.Secureusingtwoofthescrewssupplied.
21.Theremainingscrewmustbeusedtosecuretheadaptortotheconcentricterminal.
22.Whentheplumeoutletispositionedunderabalconyorotherprojection(Fig.21r)itmustprotrudeatleast200mm(itisnotnecessarytoextenditfurtherthanthis).
23.Whenunderbalconiesorprojectionsitispermissibletorotatetheconcentricfluelengthupto70°,clockwiseoranticlockwise(Fig.21s),ifthereisinsufficientspaceto
connectvertically.
24.Thiswillallowtheconnectionoftheexhausttotheoutletspigot.
25.Allotherminimum&maximumdimensionsmustbeadheredto,andtheairinletpositionedsuchthatitwillnotbesubjecttorainentry.
Fig.21n
Fig.21p
Fig.21q
Fig.21r
