Baxi ECOGEN 24/1.0 Installation & Servicing Instructions

Fig.24
Fig.25
Fig.26
page33
9.2FittingTheBoiler
1.Usingasuitableliftingdevice,lifttheapplianceonitsbasepackaging.Offertheapplianceuptothewallplateandengagethebottomedgeofthebackoftheapplianceon
tothewallplate(Figs.27&28).
Ensurethatthereisadequateclearancefortheliftingequipment(seeSection7.2).
2.Pushtheappliancebackontothewallplateandengagethesecuringnutsatthetopoftheappliancebyslidingtotherightandswingingdown(Figs.28&29).
3.Tightenthetwosecuringnutsonthewallplateandcompletethesecuringoftheappliancebyreplacingthetwoscrewspreviouslyremoved.(Figs.29&30).
4.Removethebasepackaging.
