Baxi ECOGEN 24/1.0 Installation & Servicing Instructions

7.WhenaTHINKControllerismountedinawallcradle,the5LEDReceiverfillsthespaceontheappliance.Itactsasanindicatorseefig.43andenablesuserresetstobe
carriedoutastheycannotbeperformedremotely.
WiringconnectionstoapplianceseeSection16.6
WiredTHINKControllerWallCradleControlTerminalFunction
1.Powersupply12v
2.Ground(0v)
3.DataSignal(+v)
Fig.44
10.14ToInstallthe5LEDReceiverandTHINKController
1.Isolatetheappliance.
2.Removethe5LEDReceiverfromthewallcradle(assupplied).
3.Connectthewireterminalsbetweentheroomunitwallcradleandtheappliancecontrolsinstallationarea,usingwiresuitablefor12v.(<200m)
4.Installthewallcradleinasuitableroomorhallway.(seeSection10.15)
5.Makesurethewallcradleisnotinapositionwhereitcanbeaccidentallyknockedortamperedwith.
6.RemovetheTHINKControllerfromtheapplianceandplaceitinthewallcradle.
7.Placethe5LEDReceiverontotheappliance.
8.Switchontheappliance.
9.IftheTHINKControllerhasnotbeenconfiguredasaRoomSensorcorrectly,youmayseeerror84:BSBcollision.Ifthisdoeshappen,repeatfromSection10.13
paragraph2whiletheTHINKControllerisonthewallcradle.Oncetheparametershavebeencheckeddownpowertheappliancefor10secondsandthenswitchthe
appliancebackon.
page48
10.15RoomUnitInstallationProcedure
1.Roomunitlocation:Thewallcradleshouldbelocatedinthemainlivingroomwhilegivingconsiderationtothefollowingpoints:
Theplaceofinstallationshouldbechosensuchthatthesensorcancapturetheroomtemperatureasaccuratelyaspossiblewithoutgettingadverselyaffectedby
directsolarradiationorotherheatorrefrigerationsources(about1.5metersabovethefloor)(Fig.45).
Theremustbesufficientclearancearoundtheunit,enablingittobefittedandremoved.
Important:ATRVshouldnotbefittedtotheradiatorinthesameroomastheroomsensor.
IfaTRVhasbeeninstalledonthisradiator,theTRVmustremainsetopenatalltimes,
therwisethehouseholderwillexperienceroomtemperaturecontrolproblems.
