Baxi ECOGEN 24/1.0 Installation & Servicing Instructions

Waitaminimumof6minutes30secondsbeforeworkingontheinteriorcomponentstoallowthecapacitortodischarge.
SeeSection13.3"Servicing"forremovalofcasepanel,dooretc.
14.1Supplementary&EngineIgniter(Fig.56)
1.Disconnecttheigniterplugandtheelectrodeleads,notingtheirpositions.
2.Undothescrewssecuringtheigniterandremoveitbeingcarefultoretainthewashers.
3.Reassembleinreverseorder.
14.2SupplementaryIgniterandSensingElectrodes(Fig.57)
1.Disconnecttheelectrodeleads,notingtheirpositions.
2.Removetheretainingscrewssecuringeachoftheelectrodestotheburnerdoorandwithdrawtheelectrodes.
3.Replacethesealinggaskets.
4.Reassembleinreverseorder.
Fig.56
Fig.57&Fig.58
14.3EngineIgniterandSensingElectrodes(Fig.58)
