BBK DK2810HD - Chapter Six Bom List

MATERIAL CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0260222 CD CD11C 10V220U±20%6×7 2.5 TC100
0090026 SMD RESISTOR 1/16W 22K±5% 0603 R104,R105
0310202 SMD CAPACITOR 50V 223±10% 0603 C102
0310072 SMD CAPACITOR 50V 103±10% 7R 0603 C103
0390095 SMD MAGNETIC BEADS FC160822105 L101,L100
1940001 SOCKET 2P 2.5mm XS100
2100004 CONNETION CORDS F0.6 SHAPED 10mm L103
03900579 MAGNETIC BEADS INDUCTOR RH354708 BELT L102
1860047 USB SOCKET CAB85-4Pin JK1
1980030 MICROPHONE SOCKET C3-6.35-19 MIC1,MIC2
1940008 SOCKET 8P2.0mm XS105
1634473 PCB 6 2870HD-2 FR4 D1.6 PX
MATERIAL CODE
MATERIAL NAME SPECIFICATIONS LOCATION
00003909 CARBON FILM RESISTOR 1/6270O±5% BELT
R501
00001699 CARBON FILM RESISTOR 1/447O±5% BELT
R500
00003219 CARBON FILM RESISTOR 1/2W47O±5% BELT
R682
00006239 CARBON FILM RESISTOR 1/2W220O±5% BELT
R622
0210145
METAL POLYESTER FILM CAPACITOR
CL21X 100V 104K C5
C708,C709
0210165
METAL POLYESTER FILM CAPACITOR
CL23X 63V 474±5% 5
C702~C707
02608249 CD C11 16V10U±20%5×11 C2.5 BELT
TC81,TC12,TC13,TC584~TC586,TC591~TC597,TC
599,TC800,TC801,TC850,TC851,TC600~TC604
02607879 CD C11C 16V47U±20%5×7 C2.5 BELT
TC7,TC8
02608519 CD CD11 16V47U M 5×11 C2.5 BELT
TC9,TC10,TC814,TC569,TC570,TC619,TC620,TC6
22,TC623,TC702,TC703,TC587,TC200
02607819 CD C11C 10V100U±20%5×11 C2.5 BELT
TC1~TC3,TC82
02602229 CD C11C 10V220U±20%6×7 2.5 BELT
TC4,TC5,TC6
02601819 CD C11 16V220U±20%6×12 C5 BELT
TC14,TC11,TC652,TC653,TC80,TC704
02603859 CD C11 16V470U±20%8×12 C5 BELT
TC617,TC618
02600279 CD C11 16V100U±20%6×12 2.5 BELT
TC705
0260048 CD CD11 35V470U±20%10×20 5
TC654~TC663
0260491 CD CD11K 35V680U±20% 13×20 5
TC698~TC701
Chapter Six Bom List
MICROPHONE HOLDER BOARD: 4941012
DVD RECEIVER DK2870HD(RU) BLACK
POWER AMPLIFIER BOARD: 4940418
