BBK DK2810HD - Controls and Functions

STANDBY/POWERbutton
Presstoswitchthedeviceon/intostanby
OPEN/CLOSEbutton
Presstoopen/closethedisctray
HDMIButton
SwitchHDMIoutputresolution
PLAY/PAUSEbutton
Presstoplayback/pause
STOPbutton
Presstostoptheplayback
10
12
11
REWbutton
Presstofastreverse/radiostationtuning.
FWD-button
Presstofastforward/radiostationtuning.
VFDdisplaywindow.
Disctray.
VOLUMEadjuster
Presstoadjustvolume
USBport
Microphoneinput.
2
3
4
5
6
7
8
9
1
HDMIoutput
ComponentvideooutputYCb(Pb)Cr(Pr)
Compositevideooutput
S-Videooutput
FMAntennainput
AMAntennainput
SCART-typeAVconnector
Coaxialdigitalaudiooutput
2
9
3
10
4
11
1
8
Opticaldigitalaudiooutput
Opticaldigitalaudioinput
Coaxialdigitalaudioimput
Audioinput
Stereophonicaudiooutput
Leftfrontspeakerinput(outputfromthe
build-inamplifier)
Rightfrontspeakerinput(outputfromthe
build-inamplifier)
5
12
6
13
7
14
15
2.2Controlsandfunctions
2.2.1Frontpanelcontrols
2.2.2Rearpanelconnections
