BBK DK2810HD - Introduction to IC of the Player

3.1.3 Introduction to IC of the player
Introduction to IC of the player is shown as in the following table:
Name of PCB semi-
manufactured goods
IC Type Location Number
Function
AM5888S N1
Servo Driving
AT24C04 N2
EEPROM
MT1389EE/S N3
Decode Chip
K4S641632K-UC60 N81
64M SDRAM
RT9701 N82
USB Power Switch
29LV160BE N83
16M FLASH
PCF8575DW N85
Serial to Parallel Transit
RC4558D N500
Audio Amplify
PT2597-SN N501
RDS Control
CS5340 N502
A/D Conversion
TLV272 N503, N504
Operational Amplifier
HEF4052BT N505
Electronic Switch
TAS5112DFD N507, N508
Digital Operational Amplify
TAS5508PAG N509
DSP Processing
RCLAMP0524P N201, N202
ESD Ptotection
CS8415A N800
Digital Audio Conversion
TP6317 N101
Panel Control IC
REMOT N102
IR Sensor
NCP1200P60 U501
Power Switch IC
HS817 U502, U505, U507
Photoelectric Coupler
TL431 U503, U506
Precision Voltage Stabilizer
LM7805 U508
Voltage Stabilizing Tube
KA1M0880BTU U504
Power Switch IC
Power Board
Surface Control Board
Decode Board
