4210005 MACHINE-TAPPING SCREW PM 3×8 BLACK INSTALL RADIATOR
5233174 RUBBER SPACER
9×9×
1 SINGLE-FACED WITH GLUE IN REAR SIDE,CENTER HOLE
POSITION OF POWER AMPLIFIER IC SCREW
MATERIAL CODE
MATERIAL NAME SPECIFICATIONS LOCATION
2100003 CONNETION CORDS F0.6 SHAPED 7.5mm W1,W2,W9,W17,W22
2100004 CONNETION CORDS F0.6 SHAPED 10mm W4,W7,W11,W14,W18,W21,W10
2100006 CONNETION CORDS F0.6 SHAPED 12.5mm W5,W6
2100016 CONNETION CORDS F0.6 SHAPEN 18mm W8
2100017 CONNETION CORDS F0.6 SHAPED 20mm W23
0210205 TERYLENE CAPACITOR 630V 102±5% SHAPED 5MM C501
0000274 CARBON FILM RESISTOR 1/4W47O±5% SHAPED 10 R511,R505
0000431 CARBON FILM RESISTOR 1/4W75O±5% SHAPED 10 R503
0000432 CARBON FILM RESISTOR 1/4W150O±5% SHAPED 10 R517
0000362 CARBON FILM RESISTOR 1/4W220O±5% SHAPED 10 R521
0000278 CARBON FILM RESISTOR 1/4W330O±5% SHAPED 10 R523
0000283 CARBON FILM RESISTOR 1/4W1K±5% SHAPED 10 R518
0000361 CARBON FILM RESISTOR 1/4W1.2K±5% SHAPED 10 R514
0000284 CARBON FILM RESISTOR 1/4W1.5K±5% SHAPED 10 R506,R533
0000460 CARBON FILM RESISTOR 1/4W3K±5% SHAPED 10 R540
0000289 CARBON FILM RESISTOR 1/4W4.7K±5% SHAPED 10 R522,R504
0000294 CARBON FILM RESISTOR 1/4W10K±5% SHAPED 10 R515,R524,R532,R537,R536
0000299 CARBON FILM RESISTOR 1/4W22K±5% SHAPED 10 R513
0000301 CARBON FILM RESISTOR 1/4W47K±5% SHAPED 10 R531
0010140 METAL FILM RESISTOR 1/43K±1% SHAPED 10 R520
0010062 METAL FILM RESISTOR 1/42.2K±1% SHAPED 10 R529
0010383 METAL FILM RESISTOR 1/4W2.4K±1%SHAPED10 R519
0010273 METAL FILM RESISTOR 1/424K±1% SHAPED 10 R530
0010138 METAL OXIDE FILM RESISTOR 1330O±5% SHAPED FLAT 15×9 R525
0010294 METAL OXIDE FILM RESISTOR 1W 750K±5% FLAT 12.5×7 R512
0010259 METAL OXIDE FILM RESISTOR 10.47O±5% FLAT 12.5×7 R534,R535
0010165 METAL OXIDE FILM RESISTOR 11O±5%SHAPED FLAT 15×7 R507,R516
0010275 METAL OXIDE FILM RESISTOR 133O±5% SHAPED VERTICAL 7.5 R526,R527
0010279 METAL OXIDE FILM RESISTOR 1680K±5% SHAPED 15 R501
DVD RECEIVER DK2870HD(RU) BLACK
POWER BOARD: 4940458
- 100 -
