0680087 SCHOTTKY DIODE SR560 DO-27 SHAPED R 20.5×8 D510
0680078 SCHOTTKY DIODE SR30 DO-27 SHAPED 17.5 D509
0570006 DIODE 1N4148 D508,D514
0570013 DIODE HER105 D503,D504,D506,D507,D512,D513
0570014 DIODE HER107 D501,D502
0570042 DIODE HER207 SHAPED 12.5mm D505,D511
0570045 DIODE BYW29E-200 TO-220
D516,D517 ⑤
0570047 DIODE ER802
D516,D517 ⑤
05800069 VOLTAGE REGULATOR DIODE 5.1V 1/2W BELT ZD501
0580072 VOLTAGE REGULATOR DIODE 9.1V±5% 1W SHAPED 10mm ZD502
0570032 DIODE 1N5408 D520,D521,D522,D523
0790110
FIELD EFFECT TRANSISTOR
STP460ZFP PLASTIC SEALED TO-220FP
V501
0780026 TRIODE 25551 V502,V503,V504
0690001 CONTROLLABLE SILICON MCR100-6 Q501
0880379 IC L7805 GOLD SEALED TO-220
U508 ⑥
0880247 IC MC7805CT GOLD SEALED TO-220
U508 ⑥
0880499 IC L7805CV GOLD SEALED TO-220
U508 ⑥
0880553 IC L431ACZ TO-92
U503,U506 ⑦
0882089 IC TL431 TO-92
U503,U506 ⑦
0882462 IC AZ431AZ-A TO-92
U503,U506 ⑦
0882041 IC MI431C TO-92
U503,U506 ⑦
0881480 IC NCP1200P60 DIP U501
0881500 IC 10880BTU TO-35L U504
1030007
PRESS SENSITIVITY RESISTOR
7D 471±10% 5mm RV501
1050002 HEAT SENSITIVITY RESISTOR NTC SC104MS±20% RT501
1080011 PHOTOELECTRIC COUPLER HS817 U502,U505,U507
1564912 PCB @5 1910SI4-2 VO D1.6 SX @UL
1940003 SOCKET 4P 2.5mm XS101
1940006 SOCKET 6P 2.5mm XS102
1940009 SOCKET 8P 2.5mm XS104
1940074 SOCKET 2P 7.92mm XS100
2300072 FUSE @T3.15AL 250V 3.6×10 VDE F501
3580195 HEAT RADIATION BOARD
11
×15×
25 SINGLE HOLE,NOT OXIDATION
D516,D517,V501
3580091 HEAT RADIATION BOARD 11×15×31 9905 U508
