MATERIAL CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0260222 CD CD11C 10V220U±20%6×7 2.5 TC100
0090026 SMD RESISTOR 1/16W 22K±5% 0603 R104,R105
0310202 SMD CAPACITOR 50V 223±10% 0603 C102
0310072 SMD CAPACITOR 50V 103±10% 7R 0603 C103
0390095 SMD MAGNETIC BEADS FC160822105 L101,L100
1940001 SOCKET 2P 2.5mm XS100
2100004 CONNETION CORDS F0.6 SHAPED 10mm L103
03900579 MAGNETIC BEADS INDUCTOR RH354708 BELT L102
1860047 USB SOCKET CAB85-4Pin JK1
1980030 MICROPHONE SOCKET C3-6.35-19 MIC1,MIC2
1940008 SOCKET 8P2.0mm XS105
1634473 PCB 6 2870HD-2 FR4 D1.6 PX
MATERIAL CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0090324 SMD RESISTOR 1/16W 0O±5% 0402
R704,R702,R1,R2,R4,R5,R6,R7,R97,R98,R101~
R107,R110~R115,R555~R568,R3,R60
0090445 SMD RESISTOR 1/16W 1O±5% 0402
R91,R92
0090326 SMD RESISTOR 1/16W 10O±5% 0402
R603~R606
0090195 SMD RESISTOR 1/16W 120K±5% 0603
R684~R688
0090330 SMD RESISTOR 1/16W 33O±5% 0402
R50,R51,R95,R96
0090333 SMD RESISTOR 1/1647O±5% 0402
R108,R109,R580~R582,R584~R592,R800~R807
,R518,R519
0090334 SMD RESISTOR 1/1651O±5% 0402
R671,R672
0090335 SMD RESISTOR 1/1668O±5% 0402
R827
0090336 SMD RESISTOR 1/1675O±5% 0402
R47,R810~R817
0090339 SMD RESISTOR 1/16W 100O±5% 0402 R49,C6,R21,R23,R24,R825,R853
0090342 SMD RESISTOR 1/16W150O±5% 0402
R818,R819
0090346 SMD RESISTOR 1/16W 220O±5% 0402
R510~R513
0090356 SMD RESISTOR 1/16560O±5% 0402
R45
0090362 SMD RESISTOR 1/16W 1K±5% 0402
R11,R12,R116,R117,R572,R574,R575,R700,R70
1,R130,R851,R852
0090364 SMD RESISTOR 1/16W 1.2K±5% 0402
R809
0090366 SMD RESISTOR 1/16W 1.5K±5% 0402
R200,R201,R569,R706
DVD RECEIVER DK2810HD(RU) BLACK
MICROPHONE HOLDER BOARD: 6DK2870HD-2 4941012
DVD RECEIVER DK2810HD(RU) BLACK
POWER AMPLIFIER BOARD-SMD: 2DK2870HD-1 4940418
- 105 -
