2300072 FUSE @T3.15AL 250V 3.6×10 VDE F501
3580195 HEAT RADIATION BOARD
11×15×25 SINGLE HOLE,NOT OXIDATION
D516,D517,V501
3580091 HEAT RADIATION BOARD 11×15×31 9905 U508
3580260 HEAT RADIATION BOARD 30×19.8×35 2100 NON-OXIDATION U504
5230462 MICA PAD 24×20×0.1
BETWEEN U504 AND HEAT RADIATION
BOARD
3870115 GROUND CHIP OF POWER BOARD 903 GND501,GND502
4000453 SELF-TAPPING SCREW BT 3×8H WHITE NICKEL V501,U508,D516,D517
4000564 SELF-TAPPING SCREW PWT 3×12×7H WHITE NICKEL U504
MATERIAL CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0310222 SMD CAPACITOR 25V 104±20% 7R 0603
C3 ,C5
0310191 SMD CAPACITOR 50V 30P±5% NPO 0603
C1, C2
0090029 SMD RESISTOR 1/16W 47K±5% 0603
R2
0090233 SMD RESISTOR 1/16W 4.7MO±5% 0603
R3, R4
0090002 SMD RESISTOR 1/16W 2.2O ±5% 0603
R5
0700007 SMD DIODE 14148
VD2
0970008 CERAMIC RESONATOR 2.0MHz
G1
0090008 SMD RESISTOR 1/16W 220O±5% 0603
R6
0630003
EMISSION PIPE TSAL6200
LED1
0160217 DIGITAL POTENTIOMETER EC30P16
RP1
1340190
LIGHT TOUCH SWITCH(FIVE DIRECTION)
SKQUC010
RP2
0780085 SMD TRIODE 8050D
V1
1564473 PCB 81910SI-2
2100003 CONNETION CORDS F0.6 SHAPED 7.5mm W1
3031855
SURFACE CASING OF REMOTE CONTROL
RC-073 BLACK
3041406
BOTTOM CASING OF REMOTE CONTROL
RC-073 BLACK
3051348
BATTERY CASE DOOR OF REMOTE CONTROL
RC-073 BLACK
3051349 GLASS O REMOTE CONTROL RC-073 MING PURPLE
3850124 ANODE SPRING RC026
3850125 CATHODE SPRING RC026
3850126 ANODE/CATHODE SPRING RC026
DVD RECEIVER DK2871HD(RU) BLACK
REMOTE CONTROL 5471746
