BBK DK2810HD - Page 56

- 52 -
Pin Main Alt. Type Description
68 HIGHA7
Inout
4~16MA, SR
PU
Microcontroller address 15
89 AD7
Inout
4~16MA, SR
Microcontroller address/data 7
86 AD6
Inout
4~16MA, SR
Microcontroller address/data 6
85 AD5
Inout
4~16MA, SR
Microcontroller address/data 5
84 AD4
Inout
4~16MA, SR
Microcontroller address/data 4
83 AD3
Inout
4~16MA, SR
Microcontroller address/data 3
82 AD2
Inout
4~16MA, SR
Microcontroller address/data 2
80 AD1
Inout
4~16MA, SR
Microcontroller address/data 1
79 AD0
Inout
4~16MA, SR
Microcontroller address/data 0
92 IOA0
Inout
4~16MA, SR
PU
Microcontroller address 0 / IO
77 IOA1
Inout
4~16MA, SR
PU
Microcontroller address 1 / IO
56 IOA2
Inout
4~16MA, SR
PU
Microcontroller address 2 / IO
57 IOA3
Inout
4~16MA, SR
PU
Microcontroller address 3 / IO
58
IOA4
Inout
4~16MA, SR
PU
Microcontroller address 4 / IO
