Product overview
C603016 Version: 2.7
3.4 Name plate
The name plate provides information on the equipment fitted to the Industrial PC.
1
2
3
4
5
6
7
8
9
10
11
12
13
xxxxxxxx
xxxxxxxxxxx
xxxxxxxxxxx
xxxxxxxxxxx
xxxxxxxxxxx
Fig.7: C6030_Name plate
Table11: Key - C6030 name plate
No. Description
1 Manufacturer, including address
2 Model: The last four digits indicate the product variant.
3 Serial number (BTN)
4 Date of manufacture
5 Mainboard
6 CPU
7 Main memory
8 Storage media
9 Power supply: 24 V
DC,
NEC class 2
10 MAC addresses of the Ethernet interfaces (X102-X105)
11 Symbols
Note: Here are the symbols applicable to the device such as CE, EAC, UKCA, . The
approvals of your device can be found on the name plate and in chapter 10.2 Approvals [}41].
12 FCC approval
13 Variant number: Commercial number of the order code including ordering options
