Beckhoff TwinSAFE logic FB User Manual

Function blocks
124 Function blocks for TwinSAFE logic components
Table 3-93: FB ADD outputs
Name
Permitted type
Data type
Description
Error
TwinSAFE-Out
FB-In
Standard-Out
BOOL
Error output (see diagnostic information)
AnalogOut
TwinSAFE-Out
FB-In
Standard-Out
INT16
INT32
UINT16
UINT32
1st output channel with the addition result
Table 3-94: Input and output types
Type
Description
TwinSAFE-In
TwinSAFE input of an EL1904/KL1904, e.g.
Standard-In
Standard PLC variable (output in the PLC %Q*)
FB-Out
TwinSAFE FB output
TwinSAFE-Out
TwinSAFE output of an EL2904/KL2904, e.g.
Standard-Out
Standard PLC variable (input in the PLC %I*)
FB-In
TwinSAFE FB input
TwinSAFE SC
Input of a TwinSAFE connection (TwinSAFE SC technology)
Table 3-95: Internal identifier of the FB
Type
Description
FB ADD
This description applies to BLG 1.0 (internal version number)
3.16.2.1 Diagnostic and state information for the FB ADD
Table 3-96: Diagnostic information
Value
Description
0
The AnalogOut output is correct
1
The AnalogOut output has an underflow
(is less than the smallest possible value)
2
The AnalogOut output has an overflow
(is greater than the largest possible value)
Table 3-97: Diag Message
Text ID
Meaning
Parameter 1
Parameter 2
Parameter 3
0x4080
An underflow has occurred
FB number
AnalogIn1
AnalogIn2
0x4081
An overflow has occurred
FB number
AnalogIn1
AnalogIn2
