Function blocks
84 Function blocks for TwinSAFE logic components
The error state can be connected via the 'Error' button.
NOTE
Error state
If the muting function was interrupted by an error, the user should ensure via the application that the
material can be removed from the muting area. Only then is an error acknowledgement possible.
Via the 'MutingActive' button a signal can be linked that can be used for a muting lamp, for example.
The 'MapState' and 'MapDiag' checkboxes are used to specify which FB diagnostic functions are mapped
to the cyclic process image.
