Behringer X32 Reference Manual

Page 7
2.4 DRUMS
Use one of the single channel powered Voice Solo monitors for the drummer, mounted on the short
stand and pointed towards the drummer.
Simply connect an XLR cable from the MIC/LINE IN input on the monitor (see illustration below) to
one of the monitor outs in the stage plate next to the drums (on the back left side of the stage, when
facing from the auditorium), and plug in the power cord to one of the outlets. The monitor should
then be turned on – individual volume for the monitor can be controlled by the drummer using the
volume knob. This adjusts the entire mix, customization of the mix is not available.
Figure 8 - Monitor Setup for Drums
The snare and kick drum are intended to be miced and there is a specific microphone for each.
Connect each microphone to the kick and snare inputs located under the stage plate – these have
been prelabeled and configured at the sound board.

Behringer X32 Specifications

General

Frequency range	10 - 22000 Hz
Channels quantity	40 channels
Digital sound processing	24 bit
Total Harmonic Distortion (THD)	0.006 %
Monitor out	1
Headphone connectivity	6.3 mm
USB 2.0 ports quantity	2
DJ mixer	-
Product color	Black

Weight and Dimensions

Depth	528 mm
Width	900 mm
Height	200 mm
Weight	20600 g
