BeiJer GN-9371 - Page 100

GN-9371_2_3 User Manual
Page 100 of (110)
G-series GN-9371_2_3 PIO Rev. 1.02.docx
• Input Process Image Mode#1 (Status(1word) + Compressed Input Processing Data)
Addr.
#15
#14
#13
#12
#11
#10
#9
#8
#7
#6
#5
#4
#3
#2
#1
#0
0x0000
EW
0
0
0
0
0
0
0
FP
Internal protocol Status
0x0001
Analog Input Ch0 high byte (Slot#3)
Analog Input Ch0 low byte (Slot#3)
0x0002
Analog Input Ch1 high byte (Slot#3)
Analog Input Ch1 low byte (Slot#3)
0x0003
Analog Input Ch2 high byte (Slot#3)
Analog Input Ch2 low byte (Slot#3)
0x0004
Analog Input Ch3 high byte (Slot#3)
Analog Input Ch3 low byte (Slot#3)
0x0005
Analog Input Ch0 high byte (Slot#8)
Analog Input Ch0 low byte (Slot#8)
0x0006
Analog Input Ch1 high byte (Slot#8)
Analog Input Ch1 low byte (Slot#8)
0x0007
Analog Input Ch2 high byte (Slot#8)
Analog Input Ch2 low byte (Slot#8)
0x0008
Analog Input Ch3 high byte (Slot#8)
Analog Input Ch3 low byte (Slot#8)
0x0009
Discrete In low 8pts (Slot#4)
Discrete In 8pts (Slot#2)
0x0010
Discrete In 8pts (Slot#6)
Discrete In high 8pts (Slot#4)
0x0011
Discrete In 4pts
(Slot#7)
Discrete In 4pts
(Slot#5)
Discrete In 4pts
(Slot#1)
 Input Assembly Priority :
1) Analog Input Data (Word type)
2) 8 or 16 points Discrete Input Data (Byte type)
3) 4 points Input Data (Bit type)
4) 2 points Input Data (Bit type)
•
Input Process Image Mode#2 (Uncompressed Input Processing Data without Status), Default Input
Addr.
#15
#14
#13
#12
#11
#10
#9
#8
#7
#6
#5
#4
#3
#2
#1
#0
0x0000 Discrete In 8pts (Slot#2) Empty, Always 0
Discrete In 4pts
(Slot#1)
0x0001
Analog Input Ch0 high byte (Slot#3)
Analog Input Ch0 low byte (Slot#3)
0x0002
Analog Input Ch1 high byte (Slot#3)
Analog Input Ch1 low byte (Slot#3)
0x0003
Analog Input Ch2 high byte (Slot#3)
Analog Input Ch2 low byte (Slot#3)
0x0004
Analog Input Ch3 high byte (Slot#3)
Analog Input Ch3 low byte (Slot#3)
0x0005
Discrete In high 8pts (Slot#4)
Discrete In low 8pts (Slot#4)
0x0006 Discrete In 8pts (Slot#6) Empty, Always 0
Discrete In 4pts
(Slot#5)
0x0007 Analog Input Ch0 low byte (Slot#8) Empty, Always 0
Discrete In 4pts
(Slot#7)
0x0008
Analog Input Ch1 low byte (Slot#8)
Analog Input Ch0 high byte (Slot#8)
0x0009
Analog Input Ch2 low byte (Slot#8)
Analog Input Ch1 high byte (Slot#8)
0x0010
Analog Input Ch3 low byte (Slot#8)
Analog Input Ch2 high byte (Slot#8)
0x0011
Analog Input Ch3 high byte (Slot#8)
Status
(1word)
