GN-9371_2_3 User Manual
Page 18 of (110)
G-series GN-9371_2_3 PIO Rev. 1.02.docx
5 Mechanical Setup
5.1 How to mount on Din-Rail
5.2 How to dismount on Din-Rail
As above figure in order to safeguard the FnIO module from jamming, it should be fixed onto the DIN rail with
locking level. To do so, fold on the upper of the locking lever. To pull out the FnIO module, unfold the locking lever
as above figure.
Before starting the work on the components, the voltage supply must be turned off.
