BeiJer GN-9371 - 3 Specification; General Specification

GN-9371_2_3 User Manual
Page 9 of (110)
G-series GN-9371_2_3 PIO Rev. 1.02.docx
3 Specification
3.1 General Specification
General Specification
System Power
Supply Voltage : 24Vdc nominal
Supply Voltage range : 15~32Vdc
Protection : Output current limit (Min. 1.5A) Reverse polarity protection
Power Dissipation
110mA typical @ 24Vdc
Current for I/O Module 1.5A @5Vdc
Isolation
System Power to internal logic : Non-Isolation
System Power I/O driver : Isolation
Field Power
Supply Voltage : 24Vdc typical (Max. 32Vdc)
*Field Power Range is different depending on IO Module series.
Refer to IO Module`s Specification.
Max. Current Field Power Contact
DC 10A Max.
Weight
<167g
Module Size
54mm x 99mm x 70mm
Environment Condition
Operating Temperature
-20℃ ~ 60℃
UL Temperature
-20℃ ~ 60℃
Storage Temperature
-40℃ ~ 85℃
Relative Humidity
5% ~ 90% non-condensing
Mounting
DIN rail
Shock Operating IEC 60068-2-6
Vibration/shock resistance
Based on IEC 60068-2-6
Sine Vibration
- 10 ~ 25 Hz : 0.5mm
- 50 ~ 150 Hz : 5g
- 150 ~ 1000 Hz : 2g
- Sweep Rate : 1 Oct/min, 50 cycles
Sine Vibration
- 10 ~ 25 Hz : 0.03 g²/Hz
- 25 ~ 50 Hz : 0.05 g²/Hz
- 50 ~ 150 Hz : 0.15 g²/Hz
- 150 ~ 1000 Hz : 0.01 g²/Hz
Test time : 5hrs for each test
EMC resistance burst/ESD
IEC 60068-2-27
EN 61000-6-2 : 2005
EN 61000-6-4/ALL : 2011
Installation Pos. / Protect. Class Variable / IP20
Product Certifications UL, CE, RoHS2, FCC, KC
