A.4.5 Expansion Slot Information Special Register (0x2000, 8192)
Each expansion slot has 0x20(32) address offset and same information structure.
Slot#1 0x2000(8192)~0x201F(8223) Slot#2 0x2020(8224)~0x203F(8255)
Slot#3 0x2040(8256)~0x205F(8287) Slot#4 0x2060(8288)~0x207F(8319)
Slot#5 0x2080(8320)~0x209F(8351) Slot#6 0x20A0(8352)~0x20BF(8383)
Slot#7 0x20C0(8384)~0x20DF(8415) Slot#8 0x20E0(8416)~0x20FF(8447)
Slot#9 0x2100(8448)~0x211F(8479) Slot#10 0x2120(8480)~0x213F(8511)
Slot#11 0x2140(8512)~0x215F(8543) Slot#12 0x2160(8544)~0x217F(8575)
Slot#13 0x2180(8576)~0x219F(8607) Slot#14 0x21A0(8608)~0x21BF(8639)
Slot#15 0x21C0(8640)~0x21DF(8671) Slot#16 0x21E0(8672)~0x21FF(8703)
Slot#17 0x2200(8704)~0x221F(8735) Slot#18 0x2220(8736)~0x223F(8767)
Slot#19 0x2240(8768)~0x225F(8799) Slot#20 0x2260(8800)~0x227F(8831)
Slot#21 0x2280(8832)~0x229F(8863) Slot#22 0x22A0(8864)~0x22BF(8895)
Slot#23 0x22C0(8896)~0x22DF(8927) Slot#24 0x22E0(8928)~0x22FF(8959)
Slot#25 0x2300(8960)~0x231F(8991) Slot#26 0x2320(8992)~0x233F(9023)
Slot#27 0x2340(9024)~0x235F(9055) Slot#28 0x2360(9056)~0x237F(9087)
Slot#29 0x2380(9088)~0x239F(9119) Slot#30 0x23A0(9120)~0x23BF(9151)
Slot#31 0x23C0(9152)~0x23DF(9183) Slot#32 0x23E0(9184)~0x23FF(9215)
Slot#33 0x2400(9216)~0x241F(9247) Slot#34 0x2420(9248)~0x243F(9279)
Slot#35 0x2440(9280)~0x245F(9311) Slot#36 0x2460(9312)~0x247F(9343)
Slot#37 0x2480(9344)~0x249F(9375) Slot#38 0x24A0(9376)~0x24BF(9407)
Slot#39 0x24C0(9408)~0x24DF(9439) Slot#40 0x24E0(9440)~0x24FF(9471)
Slot#41 0x2500(9472)~0x251F(9503) Slot#42 0x2520(9504)~0x253F(9535)
Slot#43 0x2540(9536)~0x255F(9567) Slot#44 0x2560(9568)~0x257F(9599)
Slot#45 0x2580(9600)~0x259F(9631) Slot#46 0x25A0(9632)~0x25BF(9663)
Slot#47 0x25C0(9664)~0x25DF(9695) Slot#48 0x25E0(9696)~0x25FF(9727)
Slot#49 0x2600(9728)~0x261F(9759) Slot#50 0x2620(9760)~0x263F(9791)
Slot#51 0x2640(9792)~0x265F(9823) Slot#52 0x2660(9824)~0x267F(9855)
Slot#53 0x2680(9856)~0x269F(9887) Slot#54 0x26A0(9888)~0x26BF(9919)
Slot#55 0x26C0(9920)~0x26DF(9951) Slot#56 0x26E0(9952)~0x26FF(9983)
Slot#57 0x2700(9984)~0x271F(10015) Slot#58 0x2720(10016)~0x273F(10047)
Slot#59 0x2740(10048)~0x275F(10079) Slot#60 0x2760(10080)~0x277F(10111)
Slot#61 0x2780(10112)~0x279F(10143) Slot#62 0x27A0(10144)~0x27BF(10175)
Slot#63 0x27C0(10176)~0x27DF(10207)
