* After the system is reset, the new “Set Value” action is applied.
** Nothing of output, input, and memory or configuration parameter corresponding slot returns Exception 02.
*** Slot Configuration parameter saved by internal EEPROM during power cycle until slot position changed.
*** All of output modules and special modules have the slot configuration parameter data. Refer to Document.
(FnIO_Configuration_Parameter_Memory_Register_Rev1.01)
• IO Data Code Format (1 word)
Item
#15
#14
#13
#12
#11
#10
#9
#8
#7
#6
#5
#4
#3
#2
#1
#0
Word
Field
Output IO code
Input IO code
Field
Date Type
Data Length
Date Type
Data Length
Example)
ST-3214
0
0
0
0
0
0
0
0
1
0
0
0
0
1
0
0
0x0084
ST-1224
0
0
0
0
0
0
0
0
1
1
0
0
0
1
0
0
0x00C4
ST-1228
0
0
0
0
0
0
0
0
0
1
0
0
0
0
0
1
0x0041
ST-4123
1
0
0
0
0
0
1
0
0
0
0
0
0
0
0
0
0x8200
ST-221F
0
1
0
0
0
0
0
1
0
0
0
0
0
0
0
0
0x4200
ST-2324
1
1
0
0
0
1
0
0
1
1
0
0
0
1
0
0
0xC4C4
Input/output Data Type: 0 0: No I/O Data / 0 1: Byte Data / 1 0: Word Data / 1 1: Bit Data
Input/output Data Length:
0 0 0 0 0 0 0: 0 Bit/Byte/Word / 0 0 0 0 0 0 1: 1 Bit/Byte/Word / 0 0 0 0 0 1 0: 2 Bit/Byte/Word
10 0 0 0 0 1 1: 3 Bit/Byte/Word / 0 0 0 0 0 1 1: 3 Bit/Byte/Word
Address
Offset
Access
Type,
Size
Description
+ 0x00(+0)
Read
1word
Slot module id. Refer to Appendix A.1 Product List.
+ 0x01(+1)
Read
1word
Expansion Slot IO code. Refer to Table IO Data Code
Format.
+ 0x02(+2) **
Read
1word
Input start register address of input image word this slot.
+ 0x03(+3) **
Read
1word
Input word’s bit offset of input image word this slot.
+ 0x04(+4) **
Read
1word
Output start register address of output image word this slot.
+ 0x05(+5) **
Read
1word
Output word’s bit offset of output image word this slot.
+ 0x06(+6) **
Read
1word
Input bit start address of input image bit this slot.
+ 0x07(+7) **
Read
1word
Output bit start address of output image bit this slot.
+ 0x08(+8) **
Read
1word
Size of input bit this slot
+ 0x09(+9) **
Read
1word
Size of output bit this slot
+ 0x0A(+10)**
Read
n words
Read input data this slot
+ 0x0B(+11)**
Read/Write
n words
Read/write output data this slot
+ 0x0C(+12) *
Read/Write
1word
Inactive slot, 0x0000:active, 0x0001:inactive
+ 0x0E(+14)
Read
1word
GT-number, if GT-22CA, returns 0x22CA
+ 0x0F(+15)
Read
String
Up to
72bytes
First 1word is length of valid character string.
If GT-22CA, returns
“00 1C 47 54 2D 32 32 43 41 2C 20 33 32 44 4F 2C 20 32
34 56 64 63 2C
20 53 6F 75 72 63 65 ”
Valid character size = 0x001E =30 characters,
"GT-22CA, 32DO, 24Vdc, Source"
+ 0x10(+16)
Read
1word
Size of configuration parameter byte
+ 0x11(+17)**
Read/Write
n words
Read/write Configuration parameter data, up to 8byte. ***
+ 0x12(+18)
Read
1word
Size of memory byte.
+ 0x13(+19)**
Read/Write
n words
Read/write Memory data. Offset of memory is fixed with 0
+ 0x14(+20)**
Read/Write
n words
Read/write Memory data. First 2byte of write data is memory
offset.
+ 0x15(+21)
Read
2words
Product code Refer to Appendix B.1 Product List.
+ 0x16(+22)
Read
2words
Catalog number. Refer to Appendix B.1 Product List.
+ 0x17(+23)
Read
1word
Firmware Revision
+ 0x18(+24)
Read
1word
Expansion Module Revision
