BELL HELICOPTER 430 - 5-27. PROGRESSIVE INSPECTION - EVENT 12 (CONT)

BHT-430-MM-2
5-00-00
Page 78 Rev. 17 1 SEP 2009
ECCN EAR99
Chapter 76 22. Examine the right engine power lever, fuel control box
assembly and control cable for looseness and correct range of
motion. Make sure they are correctly attached. (E2)
Chapter 63 23. Examine the right oil cooler blower driveshaft and
couplings for damage. Make sure they are correctly attached.
Examine the discs for cracks that radiate from the bolt holes,
corrosion, wrinkles or other signs of overstress. (E2)
Chapter 79 and
BHT-430-CR&O-V.2
24. Examine the right oil cooler blower for blockage,
cleanliness and damage. Make sure it is correctly attached. (E2)
Rolls-Royce
250-C40B Operation
and Maintenance
Manual, Publication
CSP 21000
25. Start the helicopter (BHT-430-FM-1) and do a FADEC
manual mode check.
SCHEDULED INSPECTIONS
5-27. PROGRESSIVE INSPECTION — EVENT 12 (CONT)
DATA REFERENCE INSPECTION TASK DESCRIPTION
INITIAL
MECH OTHER
