BELL HELICOPTER 430 - Table 4-2. Inspection Limitations Schedule; COMPONENT PART NUMBER INSPECTION INTERVAL (HOURS OPERATION TIME); NOTES:

BHT-430-MM-2 TC APPROVED
4-00-00
Page 10 Rev. 19 1 NOV 2012
ECCN EAR99
Table 4-2. Inspection Limitations Schedule
COMPONENT PART NUMBER
INSPECTION INTERVAL
(HOURS OPERATION TIME)
Main Rotor Yoke Assembly 430-010-101-101 100 hours
Main Rotor Yoke Assembly 430-010-101-101 150 hours
Main Rotor Yoke Assembly 430-010-101-101 600 hours
Pylon Fluid Mount 430-310-200-103/-105 600 hours
Main Rotor Yoke Assembly 430-010-101-101 2500 hours
Main Rotor Blade Assembly 430-015-001-101 2500 hours
Pylon Fluid Mount 430-310-200-107 2500 hours
NOTES:
Inspection limitation for the part number listed applies to all successive dash numbers for that component,
unless otherwise specified.
Refer to Chapter 5 for inspection check sheets.
Inspection applies to yokes with cracks greater than 3.0 inches (76.19 mm). Inspection is limited to arm
which has crack(s) greater than 3.0 inches (76.19 mm). Refer to Figure 4-1.
Refer to Figure 4-2 for inspection details.
Inspection applies to yokes with cracks less than 3.0 inches (76.19 mm). Inspection is limited to arm that
has crack(s) less than 3.0 inches (76.19 mm). Refer to Figure 4-1.
Refer to Figure 4-3 for inspection details.
This inspection does not apply to pylon fluid mount 430-310-200-107.
Refer to Figure 4-4 for inspection details.
Refer to Figure 4-5 for inspection details.
Refer to Figure 4-6 for inspection details.
