BELL HELICOPTER 430 - Figure 4-4. Main Rotor Yoke - 2500-Hour Inspection; NOTE

BHT-430-MM-2 TC APPROVED
4-00-00
Page 14 Rev. 19 1 NOV 2012
ECCN EAR99
Figure 4-4. Main Rotor Yoke — 2500-Hour Inspection
Refer to BHT-430-CR&O (Chapter 62) for
inspection and damage criteria.
1.
2.
3.
Remove main rotor yoke.
Clean main rotor yoke.
Perform a detail visual inspection of the entire
yoke for evidence of cracking, delamination
and damage. Specific attention should be
applied to the shaded areas.
