BHT-430-MM-2
5-00-00
26 JAN 2007 Rev. 15 Page 95
SCHEDULED INSPECTIONS
5-36. EVERY 2 CALENDAR YEARS
DATA REFERENCE INSPECTION TASK DESCRIPTION
INITIAL
MECH OTHER
DATE: __________________W.O. ____________________
_
FACILITY: _________________________________________
_
HELICOPTER S/N: __________________________________
_
REGISTRY NO.: ____________________________________
_
TOTAL TIME:______________________________________
_
SIGNATURE:_______________________________________
_
SWASHPLATE AND CONTROLS
Chapter 5 and
Chapter 62
NOTE
Examine the control bolts more frequently if you
operate the helicopter in adverse environmental
conditions.
1. Inspect the flight control bolts. (R1)
a. Remove the bolts that follow:
(1) Remove four bolts from the main rotor pitch link
universal bearing upper.
(2) Remove four bolts from the main rotor pitch link
universal bearing lower.
(3) Remove four bolts from the main rotor pitch link
lower.
(4) Remove two bolts from the drive hub assembly.
(5) Remove one bolt from the drive hub to idler link.
(6) Remove one bolt from the idler link to drive link.
(7) Remove one bolt from the drive link to rotating
ring.
