BELL HELICOPTER 430 - Table 5-3. Tail Rotor Driveshaft Hanger Bearing Assembly; NOMENCLATURE PART NUMBER; NOTES:

BHT-430-MM-2
5-00-00
Page 156 Rev. 18 9 SEP 2011
ECCN EAR99
Table 5-3. Tail Rotor Driveshaft Hanger Bearing Assembly
NOMENCLATURE PART NUMBER
HANGER
ASSEMBLY
222-044-003
-109
(3)(5)(7)
-111
(4)(5)(7)
-113
(5)(6)
-115
(5)(6)
NOTE
Spacer 230-044-003-101 X X X X
Spring 230-044-004-101 X X X X
Bearing 222-344-606-101 X X (1)(7)
Bearing 222-344-606-103 X X (2)(5)(6)
Adapter 222-044-626-101 X X
Adapter 222-044-626-103 X X
Adapter 222-044-627-103 X X X X
Hanger 222-044-630-101 X X X X
NOTES:
1.Bearing P/N 222-344-606-101 is replaced by bearing P/N 222-344-606-103.
2.Hanger bearings P/N 222-344-606-103 have a 3 year shelf life from date of manufacture.
New bearings will have the manufacturing/grease pack date marked on the face of the bearing outer ring
and on the seal faces. Bearing must be put in service within the 3 year shelf life/grease expiration date;
otherwise the bearing is unserviceable and must be scrapped.
3.Hanger assembly P/N 222-044-003-113 replaces hanger assembly P/N 222-044-003-109.
4.Hanger assembly P/N 222-044-003-115 replaces hanger assembly P/N 222-044-003-111.
5.All hanger assemblies including bearing P/N 222-344-606-103 have an overhaul requirement of 3000 hours.
6.A tag must be attached to any uninstalled hanger (or a bearing). The tag must specify the hanger bearing
part number, serial number and bearing grease expiration date. The expiration date is written in two-digit
form, (e.g. 02/97 – month/year).
7.Replacement of P/N 222-344-606-101 bearing with P/N 222-344-606-103 bearing, upgrades hanger
assemblies P/N 222-044-003-109 and P/N 222-044-003-111 to P/N 222-044-003-113 and P/N
222-044-003-115 hanger assemblies respectively.
