BHT-430-MM-2
5-00-00
Page 82 Rev. 15 26 JAN 2007
NOTE
Examine the duplex bearing before you lubricate the
swashplate.
f. Rotate the swashplate outer ring and make sure the
duplex bearing operates smoothly. Replace the bearing if it feels
rough.
Chapter 62 g. Measure the swashplate friction and adjust if
necessary.
NOTE
This inspection does not apply to 430-010-400-103
swashplate configuration with single piece bearing
sets and non-splitted ball sleeve guide bearings.
BHT-430-CR&O-2 h. Examine the area around the upper and lower ball
sleeve bearing sets for signs of fretting /rotation.
Chapter 62 i. Install the pitch change links and connect the drive link
to the rotating ring.
SCHEDULED INSPECTIONS
5-29. EVERY 300 HOURS OF COMPONENT OPERATION (CONT)
DATA REFERENCE INSPECTION TASK DESCRIPTION
INITIAL
MECH OTHER
