BHT-430-MM-2
5-00-00
a. If the valves have activated, you will see that the vent
lines have moved because the two halves must separate before
the valve halves seal.
b. If you see a yellow ring next to the frangible section of
the interconnect valve, the valve has actuated and should be
replaced.
22. Do a full visual inspection of the components that follow. If
you do not find any problems or damage to the components,
they may be kept in service.
a. Tail rotor hub and controls.
b. Tail rotor gearbox.
c. Tail rotor driveshafts.
d. Tail rotor driveshaft hangar assemblies.
e. Tail rotor blades.
f. Main rotor blades.
CONDITIONAL INSPECTIONS
5-46. HARD LANDING (CONT)
DATA REFERENCE INSPECTION TASK DESCRIPTION
INITIAL
MECH OTHER
26 JAN 2007 Rev. 15 Page 123/124
