BELL HELICOPTER 430 - 5-25. PROGRESSIVE INSPECTION - EVENT 10 (CONT)

BHT-430-MM-2
5-00-00
26 JAN 2007 Rev. 15 Page 69
Chapter 53 11. Examine the top and bottom surfaces of the horizontal
stabilizer for cracks in the area adjacent to the stabilizer support.
(T1/T2)
Chapter 53 12. Examine the tail rotor guard and the tail skid for damage.
Make sure they are correctly attached. (T1/T2)
CAUTION
REFER TO CHAPTER 53, TABLE 53-1 FOR
CORRECT TORQUE.
Chapter 53 13. Examine the vertical fin assembly for damage. Make sure
the vertical fin attach bolts/nuts have the correct torque Apply
torque in the tightening direction to the nut while restraining the
bolt head. If lowest value of specified torque range is reached
without nut movement, raise the torque to the highest value of
specified torque range. If the nut moves below the lowest value
of specified torque range proceed with 2 Year Inspection. (T1/T2)
NOTE
Examine inspection window(s) and sight glass(es) for
cracking and discoloration. If either of these
conditions are present the part must be removed and
replaced prior to returning helicopter for service.
Chapter 12 and
Chapter 65
14. Examine the tail rotor gearbox for oil leaks and mechanical
or corrosion damage. Make sure the gearbox has the correct
fluid level. Make sure the gearbox is correctly attached. (R2)
Chapter 65 15. Inspect tail rotor gearbox retaining nuts for proper torque.
Chapter 65 16. Remove the tail rotor gearbox chip detector. Clean and
examine the chip detector. Install the chip detector. (R2)
Chapter 64 17. Inspect tail rotor pitch control assembly as follows:
a. Check for excessive radial play between the pitch
control assembly and the tail rotor gearbox output shaft due to a
worn or debonded guide bearing. Radial play in excess of 0.018
inch (0.5080 mm) is considered excessive.
SCHEDULED INSPECTIONS
5-25. PROGRESSIVE INSPECTION — EVENT 10 (CONT)
DATA REFERENCE INSPECTION TASK DESCRIPTION
INITIAL
MECH OTHER
