Bender AGH675S-7 - Characteristic Curves

Technical data IRDH275BM-7 with AGH675S-7…
65
IRDH275BM-7_D00123_06_M_XXEN/07.2018
7.5 Characteristic curves
Current output 0…20 mA (IRDH275BM-7)
R
F
= Insulation fault in kΩ
I = Current output in mA
10
100
1000
10000
100000
0 5 10 15 20 25
I [mA]
R
F
[kW]
R
F
=
20 mA x 2800 kW
I
- 2800 kW
