iso1685DP_D00272_03_M_XXEN/08.2017
13
4. Device overview
4.1 Dimensions
ISOMETER
®
iso1685
PGH ON
246 mm
125 mm40,5 mm
40,75 mm
51 mm
368 mm
383 mm
401,5 mm
106 mm
64 mm
8,75 mm
5,2 mm
61,8 mm
76,6 mm
39,8 mm
55,7 mm
