9.2 Factory settings
Response values, alarms and profile
Switching elements
Insulation fault location (only iso1685DP)
Parameter
Value
Status
Measurement method Power circuits
Insulation response value R
an1
40k
Insulation response value R
an2
10k
Fault memory off
Coupling monitoring on
Parameter
Value
Status
Relay 1 (11/12/14)
Operating mode: N/C operation
Function: Insulation measurement
Relay 2 (21/22/24)
Operating mode: N/C operation
Function: Insulation measurement
Relay 3 (31/32/34)
Operating mode: N/C operation
Function: Device error
Parameter
Value
Status
EDS mode auto
PGH current 25 mA
BMS
Digital inputs
Other
Parameter
Value
Status
BMS address 2
BMS termination ON
Parameter
Value
Status
Digital input 1
Mode (operating mode): active high
Function: Test
Digital input 2
Mode (operating mode): active high
Function: standby
Parameter
Value
Status
Standby mode (disconnection from the
mains)
off
Permissible system leakage capacitance
depending on the set measurement method
(refer to “12. Device profiles”)
Buzzer off
Menu language German
Password query off
Password 0000
