Modbus register assignment of the ISOMETER®
44
isoEV425_D00126_09_M_XXEN/03.2019
( ) = Channel description code (refer to Chapter 8.2)
[ ] = Alarm type (refer to Chapter 8.1.2.2)
1016
to
1019
U
L1e
Voltage (76)
[no alarm]
--- --- ---
1020
to
1023
U
L2e
Voltage (76)
[no alarm]
--- --- ---
1024
to
1027
Fault location
in %
--- (1022)
[no alarm]
--- --- ---
1028
to
1031
R
UGF
Insulation
fault (71)
[no alarm]
--- --- ---
1032
to
1035
Measured
value update
counter ----
(1022) [no
alarm]
--- ---
---
Device
fault (115)
[Device
fault]
Register
Measured value
Device fault
Without
alarm
Alarm 1 Alarm 2
