Modbus register assignment of the ISOMETER®
48
isoPV425_D00028_09_M_XXEN/05.2018
3025 RW Device test during
device start "S. Ct"
UINT 16 --- 0 = Inactive
1 = Active
3026 RW
Request stop
mode (0 = deacti-
vate device)
UINT 16 ---
0 = Stop
1 = ---
3027 RW
Alarm assignment
of relay 1
"r1"
UINT 16 --- Bit 15 … Bit 0
3028 RW
Alarm assignment
of relay 2
"r2"
UINT 16 --- Bit 15 … Bit 0
8003 WO
Factory
setting for all
parameters
UINT 16 --- 0x6661 "fa"
8004 WO
Factory
setting only for
parameters reset-
table by FAC
UINT 16 --- 0x4653 "FS"
8005 WO
Start device test
UINT 16 --- 0x5445 "TE"
8006 WO
Clear fault mem-
ory
UINT 16 --- 0x434C "CL"
9800
to 9809
RO Device name
UNIT 16
(ASCII) - refer
to
Chapter 8.1.1
--- ---
9820 RO
Software
ID number
UINT 16 ---
9821 RO
Software version
number
UINT 16 ---
Register
Property Description Format
Unit
Value range
