BENDIX TABS-6 User Manual

29
FIGURE 26 - BENDIX
®
TABS -6
™
ADV MC MODULE - TYPICAL 4S/2M AXLE CONTROL ABS ELECTRICAL & AIR SYSTEM
FIGURE 27 - BENDIX TABS-6 ADV MC MODULE - 4S/2M AXLE CONTROL (180 DEGREE) ABS ELECTRICAL & AIR SYSTEM
Troubleshooting: System Schematics
P21
P22
4S/2M - AXLE CONTROL - Fixed Axles
180 Degree Mounting Orientation
Ignition
Power
Trailer Chassis Harness
Bendix
®
TABS-6
™
Advanced
Multi-Channel
Bendix
®
SR-5
™
Trailer
Spring Brake
Valve
Trailer ABS Pigtail Harness
ABS Indicator Lamp
5-Pin ABS
Connector
Supply Line
Control Line
Right - “Curb-Side”
Semi-Trailer Tandem Axle Trailer
Left - “Road-Side”
7-Pin SAE J560
Connector
Brake Lamp Power
Ground
“S-D” “S-F”
“S-E”“S-C”
Bendix
®
WS-24
™
Wheel Speed Sensors
Bendix
®
WS-24
™
Wheel Speed Sensors
Air Bellow
(where used)
Load Sensor
(where used)
4S/2M - AXLE CONTROL - Fixed Axles
0 Degree Mounting Orientation
Ignition
Power
Trailer Chassis Harness
Bendix
®
TABS-6
™
Advanced
Multi-Channel
Bendix
®
SR-5
™
Trailer
Spring Brake
Valve
Trailer ABS
Pigtail
Harness
ABS Indicator Lamp
5-Pin ABS
Connector
Supply Line
Control Line
Right - “Curb-Side”
Semi-Trailer Spread Axle Trailer
Left - “Road-Side”
7-Pin SAE J560
Connector
P21
P22
Brake Lamp Power
Ground
Bendix
®
WS-24
™
Wheel Speed Sensors
Bendix
®
WS-24
™
Wheel Speed Sensors
“S-D”
“S-F”
“S-E” “S-C”
Air Bellow
(where used)
Load Sensor
(where used)
A Brake Lamp Power
B Ignition Power
C NC
D Indicator Lamp
E Ground
A Brake Lamp Power
B Ignition Power
C NC
D Indicator Lamp
E Ground

BENDIX TABS-6 Specifications

General

Type	Trailer ABS Module
Operating Temperature Range	-40°C to +85°C
Protection Rating	IP67
Category	Automobile Accessories
Voltage	12V/24V
Communication	J1587/J1939
Mounting	Frame Mount
Manufacturer	BENDIX
System Type	ABS
Number of Channels	4S/2M
