BendPak XPR-10AS Service Manual

DIMENSIONS ARE IN MM
☺
5
1
3
4
2
ITEM
NO
PART
NUMBER
DESCRIPTION QTY REV
1 5245044 XPR-10AS LIFT SUPERSTRUCTURE 1 M
2 5250084 XPR-10AS PARTS BOX 1 F
3 5215286 XPR-10AS LOW PROFILE LONG ARM ASSEMBLY, R.H. 1 K
4 5215285 XPR-10AS LOW PROFILE LONG ARM ASSEMBLY, L.H. 1 K
5 5215284
XPR-10AS LOW PROFILE TRIPLE TELESCOPING ARM
ASSEMBLY
2 L
6 5905109 WARNING ALI/WL 101 1 -
7 5905131 2 POST DECAL KIT, LESS ALI 1 E
8 5905403 MAX CAPACITY 10K DANGER LABEL, ENGLISH-FRENCH 1 -
9 5905465 MANUFACTURER LABEL 1 -
10 5905940 PRODUCT DATA LABEL 1 -
11 5905951 SERIAL TAG B 1 -
12 5905653 LABEL; ALI-ALCTV-2017 GOLD LABEL, US; MET LABS 1 -
13 5905414 GP/XPR LOCK-RELEASE LABEL 1 -
14 5905285 SERIALTAG EXTERIOR PEEL OFF INVENTORY LABEL 1 -
15 5905655 MAX CAPACITY NTRL 10K LABEL, ENGLISH-FRENCH 1 -
16 5905377 NOTICE LABEL, ALI/WLSIA01 1 -
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
W UPDATED BOM REVISION 11/03/2020 TM 01226
X UPDATED BOM REVISION 03/29/2021 TM 01291
Y UPDATED BOM REVISION 06/23/2021 TM 01310
SHEET 1 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
Y
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
TM
5260562
XPR-10AS PRODUCTION
LIFT VER F
12/14/2015
DO NOT SCALE DRAWING
1:35
SCALE:
THIRD ANGLE PROJECTION
OR 07/07/2021
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
