ISOMETRIC VIEW
FOR REFERENCE ONLY
DO NOT SCALE
432
230
110
76
2 PL
127
30°
TYP
101
22
6 PL
190
2 PL
150
32
4 PL
109
32
2 PL
76
2 PL
109
3
MAX
6 PL
25
161
2 PL
A
16
483
25
TYP
3.0
10
45°
X
R
1.5
20
2 PL
12
30°
DETAIL A
SCALE 1 : 3
REVISION
REV
DESCRIPTION
DATE
EDITED BY
ECO#
A
PRODUCTION RELEASE, DERIVED FROM 800138
08/19/2009
TM
00293
B
UPDATED TITLE TO REFLECT WHERE USED
06/03/2010
TM
00367
C
UPDATED TITLE TO REFLECT MARKETING
11/23/2015
TM
00738
WHERE USED
XPR-10 SERIES
D2-10 SERIES
NEXT ASSEMBLY
5620352
5620683
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
C
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF
BENDPAK INC.
ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF
BENDPAK INC.
IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED.
TM
DIMENSIONS ARE IN MM
TOLERANCES: MACHINE TO
0 = ±1.5
0.0 = ±0.5
0.00 = ±0.13
SURFACE FINISH 1.6 Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED
5736296
XPR-10 BASE PLATE
DO NOT SCALE DRAWING
1:5
SCALE:
THIRD ANGLE PROJECTION
CA
02/08/2016
REFER TO MODEL FOR ADDITIONAL INFORMATION
1.
BREAK AND DEBURR ALL SHARP EDGES 0.3mm
2.
MATERIAL:
HR ASTM A36 OR Q235 GB/T 700
3.
FLAME CUT EDGES PERMISSABLE
4.
08/19/2009
