DIMENSIONS ARE IN MM
3
1
2
ISOMETRIC VIEW
FOR REFERENCE ONLY
DO NOT SCALE
NEXT ASSEMBLY
5260559
5260560
5260561
5260562
ITEM NO
PART NUMBER
DESCRIPTION
QTY
REV
1 5215388
XPR-10 POWER SIDE POST ASSEMBLY
1
Y
2 5215389
XPR-10 OFF SIDE POST ASSEMBLY
1
Y
3 5210211
XPR-10A TOP TROUGH ASSEMBLY
1
D
REVISION
REV
DESCRIPTION
DATE
EDITED BY
ECO#
K
UPDATED BOM REVISION
02/21/2020
TM
01107
L
UPDATED BOM REVISION
11/03/2020
TM
01226
M
UPDATED BOM REVISION
03/29/2021
TM
01291
WHERE USED
XPR-10AS
XPR-10AS-168
XPR-10AS-LP
XPR-10AS-168-LP
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
M
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF
BENDPAK INC.
ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF
BENDPAK INC.
IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED
.
TM
5245044
XPR-10AS LIFT
SUPERSTRUCTURE
10/07/2014
DO NOT SCALE DRAWING
1:30
SCALE:
THIRD ANGLE PROJECTION
OR
03/31/2021
REFER TO MODEL FOR ADDITIONAL INFORMATION
1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING
2.
ASSEMBLE ITEMS AS SHOWN
3.
