BendPak XPR-10AS Service Manual

3677.5mm
144.78in
[9.626-84.626in]
242.9-2149.5mm
WITH 63mm [2.5in] ADAPTER
AND MAX ADJUSTMENT
[106.185-114.165in]
2697.1-2899.8
[4.917-79.917in]
125.0-2029.9mm
[133.307-141.343in]
3386.0-3590.1
B B
2382.0- 2585.0 mm
DRIVE THRU
[93.780-101.772in]
3480.0- 3683.9 mm
[137.008-145.035in]
[23.425-43.700in]
595.1-1110mm
[40.315-58.031in]
1023-1474mm
SECTION B-B
SHEET 2 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
Y
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
5260562
XPR-10AS PRODUCTION
LIFT VER F
1:45
SCALE:

BendPak XPR-10AS Specifications

General

Brand	BendPak
Model	XPR-10AS
Category	Lifting Systems
Language	English
