Benelli TRK 502 User Manual

TRK 502/ 502X
26
PRIMARY PARTS
FUEL TANK
The capacity of fuel tank (including reserve) is about 20L.
To open fuel tank cap, please insert the key and turn it clockwise and open the cover. To close the fuel tank, please
recap and then press it. Take away the key when you hear the sound of locking.
E5 E10
1
2
1.Gasoline containing up to 5% ethanol by volume.
2.Gasoline containing up to 10% ethanol by volume.
Use fuel identied by either of the above symbols.
Alarm：
Gasoline is extremely ammable and can be explosive under certain conditions, creating the potential for serious
burns. Turn the ignition switch o. Do not smoke. Make sure the area is well ventilated and free from any source of
ame or sparks; this includes any appliance with a pilot light. Never ll the tank completely to the top.
If the tank is lled completely to the top, heat may cause the fuel to expand and overow through the vents in the
tank cap. After refueling, make sure the tank cap is closed securely. If gasoline is spilled on the fuel tank, wipe it o
immediately.
Note：
Never ll the tank so the fuel level rises into the ller neck. If the tank is overlled, heat may
cause the fuel to expand and ow into the Evaporative Emission Control System resulting in
hard starting, engine hesitation and non-compliance with the emission regulation.
1
2
3
1. Fuel tank ller neck
(if equipped)
2. Bottom of ller neck
(maximum fuel level)
3. Top level

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
