Benelli TRK 502 User Manual

TRK 502/ 502X
51
Ination pressure and tire tread should be regularly checked. In order to ensure maximum safety and longer
service life, ination pressure requires more frequent routine check.
Tire Pressure
Insucient tire pressure will not only accelerate wearing, but also have bad impact on driving stability such as
making turning dicult. However, too high pressure will reduce the contact area between tire and ground, thus
causing slipping or even getting out of control. Tire pressure should be kept in the standard range. Adjust the tire
pressure under a "cold" condition.
INSPECTION& MAINTENANCE
Notice:
Adjustment of valve clearance will have direct inuence on the performance of engine, thus requiring
strict accordance with the time interval required in "Maintenance Schedule". Adjustment should be done
with professional technicians corresponding tools. In order to keep the valve clearance in good condition,
we strongly recommend you to leave it up to consult to authorized dealers about this maintenance.
220kpa
Front Wheel
250kpa
Rear Wheel
TIRE

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
