Benelli TRK 502 User Manual

TRK 502/ 502X
33
SMOOTH LAUNCHING
Hold the clutch lever, paused for an instant and step on the shift pedal to the rst gear. Twist the throttle grip
towards yourself and release the clutch lever slowly and smoothly at the same time. Then the motorcycle will begin
to move forward smoothly.
Gear box usage
Gear box can ensure a smooth running of engine within normal engine rpm Driver should choose a proper gear
according to driving speed. It is dangerous to drive with clutch disengaged. Lower the gear when you slow down
the motorcycle to make engine run within normal rpm range.
Drive on slope way
When drive on uphill road, motorcycle will slow down and seem to be lack of power. Switch to low gears so that
engine can generate normal power. Shift the gear swiftly to prevent motorcycle from losing speed.
Turn to low speed gears in order to brake when driving on downhill slope.
Don't over rev the engine.
Brake usage and stopping
Warning:
Put the stands back to retracted position before driving.
INSPECTION& MAINTENANCE

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
