TRK 502/ 502X
38
Be repaired by authorized dealers: with qualied tools and inspection materials provided by the owner; by
persons with mechanical repair certication; required to be followed the maintenance manual for self-inspection.
Examination and repair are suggested to be taken by authorized dealers for the sake of safety, in cases of these
items
Notes:
1. Make more inspections for driving in dusty areas.
2. Repeat the shown regular inspection, if the odometer reading exceeds the xed value.
3. Take more maintenance to keep good performance for frequent driving in heavy conditions as rugged roads.
OIL LEVEL & OIL CHANGE
Check the oil level before starting the engine.
Put the motorcycle on side stand. Pull the handle bar and
let the bike stand vertical to the at ground. Check if the oil
level is between the maximum and minimum level. If not, ll
the qualied engine oil to the proper amount.
Oil Change & Oil Filter Replacing
1. Take down the oil lter with the special tool and oil drain
bolt before oil draining.
2. Replace the oil lter with a new one if needed.
INSPECTION BEFORE DRIVING
2
3
1
2

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
