TRK 502/ 502X
43
f. The six sealing plugs on the cover strip align respectively to the six lling ports on the battery. Make sure the
ends of the six sealing plug has inserted into the lling ports on the battery; press them hard into the ports till the
cover strip makes a plane with the top surface of the upper part of the battery.
After completion of electrolyte lling, please do not pull out the cover strip or ll water, electrolyte or other liquid.
Pay attention to the following matters while replacing the battery.
Before replacing the battery, please rst determine the model of motorcycle and check if both batteries are of the
same type. During motorcycle design, the battery specications are considered as the best choice. If a battery of a
dierent model is used, it may aect performance and life time of the motorcycle, and possibly causes
electrical failure.
If the motorcycle will not be used for a long time, please remove the battery and charge it once a month.
THROTTLE CABLE ADJUSTMENT
1. Screw o the lock nut. 2. Turn the adjustor to make the cable clearance within10-20mm.
3. Retighten the lock nut after adjustment of cable clearance.
INSPECTION& MAINTENANCE
Warning：Battery will produce explosive gases when chemical reaction occurs in the battery.
Keep the battery away from re, spark and high temperature places.
The battery is lled with sulfuric acid (electrolyte). Electrolyte is poisonous substance.
Please keep it out of reach of children.

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
